Pot 16mm Single Lin(B) 250K
Solder Lugs
Maximize
| Product | From (qty) | Discount |
|---|---|---|
| Pot 16mm Single Lin(B) 250K | 20 | -40% |
| Pot 16mm Single Lin(B) 250K | 10 | -25% |
| Pot 16mm Single Lin(B) 250K | 5 | -15% |
- Shaft Diameter: 6mm
- Shaft Height: 15mm
- Shaft Type: Knurled
- Body Diameter: 16mm
- Soldering: Wire Lugs
| Electrical characteristics | |
| Total Resistance | 500Ω-2MΩ |
| Total Resistance Tolerance | ±20% |
| Resistance Taper | A.B.C |
| Max. Operating Voltage | Single Unit: AC50V/DC20V;Dual Unit: DC 20V |
| Rated Power | 0.05W,Dual Unit:0.03W |
| Sliding Noise: | less than 100mV |
| Insulation Resistance | More than 10OMΩ at DC 250V) |
| Residual Resistance | Term.1~2:less than 20 Ω ;Term.2~3: less than 20Ω |
| Gang Error (Dual Unit) | -40dB~0dB ± 3dB |
| Mechanical characteristics | |
| Total Rotational Angle | 300°C+/-5°C |
| Rotational Torque | 10gf.cm~100gf.cm |
| Rotational Stopper Strength | 3.0Kgf.cm Min |
| Push-Pull Strength | 8.0kgf min |
| Click torque | 50gf.cm~180gf.cm |
