Pot 16mm Single Lin(B) 2K Maximize

Pot 16mm Single Lin(B) 2K

Solder Lugs

More details

P-103

Product From (qty) Discount
Pot 16mm Single Lin(B) 2K 20 -40%
Pot 16mm Single Lin(B) 2K 10 -25%
Pot 16mm Single Lin(B) 2K 5 -15%
  • Shaft Diameter: 6mm
  • Shaft Height: 15mm
  • Shaft Type: Knurled
  • Body Diameter: 16mm
  • Soldering: Wire Lugs
Electrical characteristics
Total Resistance 500Ω-2MΩ
Total Resistance Tolerance ±20%
Resistance Taper A.B.C
Max. Operating Voltage Single Unit: AC50V/DC20V;Dual Unit: DC 20V
Rated Power 0.05W,Dual Unit:0.03W
Sliding Noise: less than 100mV
Insulation Resistance More than 10OMΩ at DC 250V)
Residual Resistance Term.1~2:less than 20 Ω ;Term.2~3: less than 20Ω
Gang Error (Dual Unit) -40dB~0dB ± 3dB



Mechanical characteristics
Total Rotational Angle 300°C+/-5°C
Rotational Torque 10gf.cm~100gf.cm
Rotational Stopper Strength 3.0Kgf.cm Min
Push-Pull Strength 8.0kgf min
Click torque 50gf.cm~180gf.cm
